An energy efficient window is one whose label shows a low U-factor (it holds heat in), an SHGC suited to your climate (it lets in the right amount of sun), and low air leakage. Those three numbers, printed on the NFRC label, tell you far more than the words ‘high performance’ on a brochure. This guide explains each rating, what ENERGY STAR asks for, and how to decide whether new windows are the right move for your house.
The honest summary: ratings are useful for comparing windows against each other, but the savings you can expect depend on what you have now and where you live. DOE says upgrading to ENERGY STAR windows can save as much as 7% to 15% or more on annual household energy bills, depending on location and the type of window being replaced. [1] That is a best case, not a promise, so the rest of this article helps you size your own case.
- Compare windows on the NFRC label: U-factor, SHGC, visible transmittance, and air leakage.
- Ask for whole-unit ratings, not center-of-glass numbers. [2]
- ENERGY STAR limits differ by climate zone, so check the zone as well as the badge. [3]
- Published estimates run from about 6% to 15% or more, depending on location and what you are replacing. [4] [1]
- Air seal and insulate first; windows come after cheaper fixes.
The four numbers on the NFRC label
Every rated window carries a National Fenestration Rating Council label. It is the one place where unlike products are measured the same way, so it is the tool to use when two quotes look equal. DOE advises looking for the ENERGY STAR label, the NFRC label, and the performance ratings when you buy. [2]
U-factor measures how well a window insulates. For windows it generally ranges from 0.20 to 1.20, and lower is better. [1] Another reference gives a typical label range of 0.10 to 2.00 and says a lower number means less heat loss. [5] The ranges differ by source, so a number outside the first range is not necessarily a mistake.
Solar heat gain coefficient (SHGC) measures how much of the sun’s heat comes through the window. It runs from 0 to 1, and a lower number lets in less solar heat. [1] Visible transmittance describes how much daylight passes through, and generally ranges from 0.20 to 0.80. [4]
Air leakage can also be listed on the label, and ENERGY STAR caps it at 0.3 cfm/ft2 for windows. [3] Condensation resistance, another item you may see, runs from 1 to 100, where a higher number means less condensation. [5]
- U-factor: lower means less heat loss, which matters most in cold climates.
- SHGC: lower blocks more sun, which matters most for cooling-dominated homes and west-facing glass.
- Visible transmittance: higher means more daylight, a comfort and lighting question rather than a bill question.
- Air leakage: lower means fewer drafts through the unit itself.
Whole-unit ratings beat center-of-glass ratings
Window makers sometimes quote the rating for the middle of the glass only, which leaves out the frame and edge of the unit and so can flatter the product. DOE tells shoppers to look for whole-unit U-factors and SHGCs rather than center-of-glass numbers. [2]
In practice, ask for the NFRC label values for the exact model and size on the quote. If a salesperson cites only a glass spec, a gas fill, or a marketing name, that is not the rating you need. A window that lists a certified whole-unit U-factor and SHGC is one you can compare line by line against another.
What ENERGY STAR requires, by climate
ENERGY STAR sets different limits for four climate zones. Under Version 7.0, which took effect October 23, 2023, the zones map to IECC zones: Southern covers 1 and 2, South-Central 3, North-Central 4, and Northern 5 through 8. [4]
The U-factor and SHGC limits for windows and sliding glass doors are: Northern, U-factor at or below 0.22 and SHGC at or above 0.17; North-Central, 0.25 and at or below 0.40; South-Central, 0.28 and at or below 0.23; Southern, 0.32 and at or below 0.23. [3] The spec also caps air leakage for windows at 0.3 cfm/ft2, and products must carry NFRC-certified ratings. [3]
The pattern is the point: cold zones push U-factor down and allow solar heat in, while hot zones tolerate a higher U-factor but want a low SHGC. Buying a window rated for the wrong zone can cost you comfort even if it is certified.
A note on ‘Most Efficient’ windows
ENERGY STAR also publishes a tier above the standard one. BASC says the Most Efficient criteria require a U-factor of 0.20 or lower, and that a U-factor at that level likely indicates a triple-pane window. [4] The Most Efficient criteria published for calendar year 2025 were a proposed version released in July 2024, so check the current ENERGY STAR page for final values before relying on specific numbers. [6]
What makes the glass and frame perform
ENERGY STAR windows use double or triple panes of glass with inert gases such as argon between them, plus better frames, spacers, and low-e coatings. [1] Double-glazed windows balance cost and efficiency, while triple-glazed windows use three panes and are the most efficient. [7]
Low-e coatings are transparent metallic layers, thinner than human hair, applied to the surfaces of glass. [7] A gas fill in the gap between panes boosts efficiency in cold or hot climates. [7] You cannot see any of this from the showroom floor, which is another reason to rely on the label instead of the sales pitch.
Frame material matters too, but the label already folds it in. That is why the whole-unit rating is the number to trust: it reflects glass, gas, spacer, and frame together.
What savings to expect, and why sources disagree
Published savings estimates vary. DOE gives 7% to 15% or more on annual household energy bills. [1] BASC says ENERGY STAR windows can save about 6% to 13% on utility bills. [4] A third reference says replacement ENERGY STAR windows cut bills by an average of 13%. [5]
The National Park Service, writing about historic buildings, takes a more cautious view. It says studies have shown that window replacement does not pay for itself in energy savings in a reasonable length of time, and notes that DOE documented air loss through windows at only about 10% of total air loss in most buildings. [8] DOE itself warns that new windows can be a considerable investment with a potentially extended payback period. [1]
Read those together and the sensible conclusion is that savings are real but depend heavily on what you are replacing. Swapping failing single-pane units in a cold climate is a different case from swapping decent double-pane windows in a mild one.
A decision rule before you buy
DOE advises making sure you have already insulated and air sealed your home before replacing windows. [1] Sealing uncontrolled air leaks alone can save 10% to 20% on heating and cooling bills, according to DOE. [2] Those jobs usually cost less than window replacement.
If your windows are single pane or badly leaky, compare three routes on cost per unit of savings: repair and weatherstrip, add low-e storm windows, or replace. DOE says replacing single-pane windows with double-pane windows that have high-performance glass may be cost effective, though exterior storm windows are an alternative. [2]
Whichever route you choose, buy on the whole-unit label, match the zone, and get written ratings for every window on the quote. For a house built before 1978, plan for lead-safe work practices first. [1]
FAQ
What is a good U-factor for a window?
For windows, U-factor generally ranges from 0.20 to 1.20, and lower is better. [1] ENERGY STAR sets a ceiling by zone, from 0.22 in the Northern zone to 0.32 in the Southern zone. [3]
Does a lower SHGC always help?
No. A lower SHGC blocks more solar heat, which helps in hot climates, but in cold climates some solar gain is welcome. The ENERGY STAR Northern zone actually sets a minimum SHGC of 0.17 rather than a maximum. [3]
Are triple-pane windows worth it?
They are the most efficient glazing type, but cost and payback depend on your climate and what you have now. [7] Compare the label numbers and the price difference rather than assuming more panes pay off.
Where do I find the ratings on a window?
Look for the NFRC label attached to the unit, and the ENERGY STAR label if it is certified. DOE recommends checking both when buying. [2]
Can I just add storm windows instead?
Often yes for older single-pane windows in decent condition. DOE lists exterior storm windows as an alternative to replacement. [2]
Most homes built before 1978 contain lead paint, which can be a serious hazard during window renovation, so use lead-safe practices or a certified renovator for older homes. [1] New windows installed into a tightened house also change ventilation, so keep bath and kitchen exhaust working.
Sources
- Consumer Guide to Energy-Efficient Windows (DOE/EE-2468). U.S. Department of Energy (EERE), accessed 2026-10-12
- Tips on Saving Money and Energy in Your Home (Energy Saver Guide, 2022). U.S. Department of Energy (EERE), accessed 2026-10-12
- ENERGY STAR Program Requirements for Residential Windows, Doors, and Skylights, Version 7.0 (Final Specification). U.S. EPA ENERGY STAR, accessed 2026-10-12
- High-Performance (ENERGY STAR) Windows. U.S. DOE Building America Solution Center (PNNL), accessed 2026-10-12
- Window Ratings (NFRC label ratings explained). Efficient Windows Collaborative, accessed 2026-10-12
- Proposed ENERGY STAR Most Efficient 2025 Recognition Criteria for Residential Windows and SGD (released July 2024). U.S. EPA ENERGY STAR, accessed 2026-10-12
- Glazing, Gas Fills and Low-E Coatings (Types and Parts). Efficient Windows Collaborative, accessed 2026-10-12
- Preservation Brief 3: Improving Energy Efficiency in Historic Buildings. National Park Service, Technical Preservation Services, accessed 2026-10-12
